Analog Microphone

This module integrates an analog microphone front end built around an MCP6001 rail-to-rail op amp on a compact 22 × 22 mm PCB. The electret microphone is amplified using an inverting amplifier configuration, with an onboard potentiometer that lets you smoothly adjust the gain to match everything from quiet ambient sounds to louder audio sources. The circuit provides a clean, fully analog output voltage that’s easy for microcontrollers, ADCs, or analog signal chains to sample without extra conditioning. It fits seamlessly into AX22 systems with no special wiring and is ideal for sound reactive projects, audio level sensing, or basic audio analysis where a simple, tunable mic amplifier is all you need. Use it standalone with any microcontroller, or snap it into the Genesis Modular system from Axiometa for plug-and-play integration. Works with Arduino IDE, MicroPython, or MicroBlocks.

- 22 mm × 22 mm Board
- 4× ⌀2.7 mm Mounting Holes
- Electret Microphone + MCP6001 Op Amp
- Analog Audio Output
- Rail-to-Rail Amplification
- 1.8 V, 3.3 V, 5.0 V Compatible
- Arduino IDE Compatible
- MicroPython Compatible
- MicroBlocks Compatible

Material Datasheet
Circuit Schematic
3D Model (STEP)
Pinout Diagram
