Tactile LED Button

Add a clicky button with built-in LED feedback to your projects. This tactile switch module features a large 12mm button with a crisp mechanical feel, hardware debouncing for clean signal readings, and an integrated white LED for visual confirmation. Perfect for user interfaces, control panels, or any application where you need reliable button input with illumination. The onboard RC filter eliminates bounce, so you get clean press detection without extra code. The LED can be controlled independently, letting you indicate status, provide feedback, or create attention-grabbing effects. The button comes in different cap colors to match your project's aesthetic, while the white LED stays consistent across all variants. Use it standalone with any microcontroller, or snap it into the Genesis Modular system from Axiometa for plug-and-play integration. Works with Arduino IDE, MicroPython, or MicroBlocks.

- 22 mm × 22 mm Board
- 4× ⌀2.7 mm Mounting Holes
- 12 mm Tactile Switch
- Built-in Addressable LED
- Digital Input + LED Output
- 3.3 V, 5.0 V Compatible
- Arduino IDE Compatible
- MicroPython Compatible
- MicroBlocks Compatible

Material Datasheet
Circuit Schematic
3D Model (STEP)
Pinout Diagram
